PERFORMANCE OPTIONS FOR YOUR NEEDS
Zebra’s G-Series™ GX™ desktop printer provide the fastest print speeds with the widest range of cutting-edge features and options, including Ethernet and an LCD screen with Wireless or Bluetooth®. Extended media handling capabilities include peel and present, precision cutter for labels, receipts and tags, and linerless labels.
Industry
- Healthcare
- Transportation and Logistics
- Retail
- Manufacturing
Available in both thermal transfer (GX420t) and direct thermal (GX420d) models, these printers combine an intuitive design and optional LCD user interface with ultra-fast print speeds and versatile connectivity options.
-
- PRINT METHOD
Thermal Transfer and Direct Thermal
-
- PRINT WIDTH
4.09”/104 mm
-
- PRINT RESOLUTION
203 dpi
-
- MAXIMUM PRINT SPEED
6”/152 mm per second
-
- MEDIA SENSORS
-
- Standard
Fixed transmissive and reflective sensors
- Optional
Multi-position transmissive and full width reflective sensor
-
- COMMUNICATION METHODS
-
- Standard
- RS-232 auto-sensing serial interface, DB-9
- USB V1.1, bi-directional
- Centronics Parallel
- Optional
- Ethernet – 10/100 internal offered in combination with USB & Serial interface (replaces Parallel port)
Available in both thermal transfer (GX420t) and direct thermal (GX420d) models, these printers combine an intuitive design and optional LCD user interface with ultra-fast print speeds and versatile connectivity options.
-
- PRINT METHOD
Direct Thermal
-
- PRINT WIDTH
4.09”/104 mm
-
- PRINT RESOLUTION
203 dpi
-
- MAXIMUM PRINT SPEED
6”/152 mm per second
-
- MEDIA SENSORS
-
- Standard
Fixed transmissive and reflective sensors
- Optional
Multi-position transmissive and full width reflective sensor
-
- COMMUNICATION METHODS
-
- Standard
- RS-232 auto-sensing serial interface, DB-9
- USB V1.1, bi-directional
- Centronics Parallel
- Optional
- Ethernet – 10/100 internal offered in combination with USB & Serial interface (replaces Parallel port)
- Retail :
Price marking, Gift registry, coupon & receipt printing, Pharmacy prescription labeling
- Healthcare :
Specimen labeling, Patient tracking
- Manufacturing :
Light-industrial work-in-process & product labeling
- Security :
Visitor ID, Evidence tracking, Parking passes
- Travel & Hospitality :
Boarding passes, Bag tags, Ski lift tickets
-
Ethernet – 10/100 internal offered in combination with USB v1.1 & Serial interface (replaces Parallel port) -
Dispenser (peeler) – Label peel and present with present sensor -
Cutter: - Continuous paper, linered label & tag stock - Maximum thickness 0.0069” (0.175 mm) -
64 MB Flash Memory with Real-Time Clock – total of 68 MB (65.5 MB available to user) for applications requiring additional levels of memory, time and date information -
Adjustable Media Sensor – full-width reflective black line sensor and multi-position gap sensor -
Font Packs – Asian and other international font kits -
ZKDU™ – Keyboard Display Unit for stand-alone printing applications where space is limited -
KDU Plus™ – full-size keyboard with LCD for standalone printing applications
